48in AllSource Triple Door Blast Cabinet

The AllSource 48-inch Triple Door Blast Cabinet is designed for blasting large parts that are difficult to fit inside standard cabinets. Its triple-door configuration features a full-width top door and two side access doors, making it easier to load and maneuver large components such as body panels, frames, and fabricated metal parts.

A rear-mounted 90 CFM dust collector helps maintain visibility during blasting operations, while the included foot pedal allows convenient hands-free control. The cabinet also features built-in fluorescent lighting, a pressure regulator, and replaceable window underlays to support long-term operation and maintenance.

Specifications:

• Work Area: 48" W x 23" H x 24" D
• Main Door Opening: 15" x 47"
• Side Door Openings: (2) 20" x 22"
• Height with Door Open: 82"
• Operating Pressure: 80–110 PSI
• Air Consumption: 15–20 CFM @ 80 PSI
• Grate Capacity: 150 lbs
• Shipping Weight: 365 lbs
• Assembly Required
• Replacement Parts

Not all replacement parts are listed. Please call for pricing and availability.

4150042 – Nozzle Retainer Nut for 41500 & 41800 Siphon Gun
4150052 – Air Jet for 41200, 41500 & 41800 Siphon Gun
41912 – 6 mm Ceramic Nozzle Kit for 41200, 41500 & 41800 Siphon Gun
40287 – Replacement Motor for Dust Collectors
5150059 – Siphon Gun for 41500 & 41800 Abrasive Blast Cabinet
4150064 – Air Inlet Adapter for 41500 & 41800
4150029 – Dust Collector Filter for Cabinets
4150066 – 6 mm Tungsten Carbide Nozzle for Use with Cabinets
