CFP 1300 Fire Suppression System With Pressure Switch
The CFP 1300 is an all-purpose easy to install unit that addresses up to 10' x 10' x 13'. Standard building offices, conference rooms, storage areas, grow rooms, lithium-ion battery applications, any space where there is a water restriction or lack of water capacity the CFP 1300 is used. Our CF-33 dry chemical agent is non-corrosive, non-conductive and non-toxic, making it a safe option for nearly any application.
This fire suppression unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155°F (68°C). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Farenheit and Celcius measurements. The temperature of the sprinkler head fixed and must be designated at the time of purchase. When the temperature rise to contents on less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.
Specifications:
Maximum Total Flood Volume: 10'x10'x13' = 1300ft³ / 3.05mx3.05mx3.96m = 36.84m³
Reach Coverage Area: 10'x10' = 100ft² / 3.05mx3.05m = 9.30m²
Temperature Rating: -20°F to 120°F / -29°C to 49°C
Cylinder Manchester: 11#
Diameter: 12.25" / 31cm
Height: 8.38"+3.50 Coupling Assembly / 21.27cm+8.90cm
Capacity: 10lbs / 4.54kg
Unit Weight: 24lbs / 10.89kg
Ship Weight: 32lbs / 14.52kg
Approvals: UL, ULC, CSFM, NYC #5754
Propellant: High Purity Compressed Dry Nitrogen
Standard System Activation: 155° Fahrenheit / 68.3° Celsius
****Please contact us for SDS Sheets, Approvals and Documentation****
Contact Us For A Current Freight Quote On This Item
Shipping Options: ( Standard shipping runs 4- 5 weeks due to each unit is custom built per order)
RUSH Is 2-3 Weeks and Expedited RUSH at 1 Week Or Sooner - Please Contact Us For Pricing
