CFP 640 Fire Suppression Unit With Pressure Switch
The CFP 640 bridges the difficult gap between small spaces and mid-size spaces. It is a Dry Chemical unit designed to install vertically. It protects any space 8' x 8' x 10' or smaller. Great for modular spaces, portable shelters, storage rooms, or any space that requires automatic fire suppression or as part of a networked system for applications eight foot wide but longer in length like a Conex box. Our CF-33 Dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for any application.
Our fire suppression units are self activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155° (68°C). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designed at the time of purchase. When the temperature rise to activate this fire suppression unit , the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time at the time of discharge to activate accessory equipment such as an alarm
**UL Listed**
Specifications:
Maximum Total Flood Volume8.2'x8.2'x10' = 672.4ft³ / 2.49mx2.49mx3.05m
= 18.91m³
Reach Coverage Area 8.20'x8.20' = 64.24ft² / 2.5mx2.5m = 6.25m²
Temperature Rating -20°F to 120°F / -29°C to 49°C
Cylinder Worthington
Diameter 7.50" / 19.05cm
Height 11.38"+3.50" Coupling Assembly /
29cm+8.90cm
Capacity 7lbs / 3.18kg
Unit Weight 19.25lbs / 8.73kg
Ship Weight 23.25lbs / 10.55kg
Approvals UL, ULC, CSFM, NYC #5754
Propellant High Purity Compressed Dry Nitrogen
Standard System Activation: 155° Fahrenheit / 68.3° Celsius
***Please contact us for SDS Sheets Approvals and Documentation****
Contact Us For A Current Freight Quote On This Item
Shipping Options: ( Standard shipping runs 4- 5 weeks due to each unit is custom built per order)
RUSH Is 2-3 Weeks and Expedited RUSH at 1 Week Or Sooner - Please Contact Us For Pricing
